不锈钢洁净阀/接头
快装盲板 TC-BF
Part no. | Size | A | B | ||
3A | DIN | ISO1127 | |||
TC-BF025 | 1/2"-3/4" | - | - | 25.2 | 6.4 |
TC-BF034 | DN10-20 | DN17.2-21.3 | 34 | 6.4 | |
TC-BF050 | 1"-1 1/2" | DN25-40 | DN26.9-42.4 | 50.5 | 6.4 |
TC-BF064 | 2" | DN50 | 48.3 | 64.0 | 6.4 |
TC-BF078 | 2-1/2" | - | 60.3 | 77.5 | 6.4 |
TC-BF091 | 3" | DN65 | 76.1 | 91.0 | 6.4 |
TC-BF106 | - | DN80 | 88.9 | 106.0 | 7.9 |
TC-BF119 | 4" | DN100 | - | 119.0 | 7.9 |
TC-BF130 | - | - | 114.3 | 130.0 | 7.9 |
TC-BF155 | - | DN125 | 139.7 | 155.0 | 11.1 |
TC-BF167 | 6" | - | - | 166.8 | 11.1 |
TC-BF183 | - | DN150 | 168.3 | 183.0 | 11.1 |
TC-BF218 | 8" | - | - | 217.7 | 11.1 |
TC-BF234 | - | DN200 | 219.1 | 233.5 | 11.1 |
TC-BF269 | 10" | - | - | 268.5 | 11.1 |
TC-BF319 | 12" | - | - | 319.3 | 11.1 |
